Profile, performance, materials and standards for the Mosaic 2027 line of windows and doors. Ranges span the available glazing options, and final values are set per project from the signed drawings.
Frame depth drives thermal performance; sight line drives how much glass you see. Glazing bead is 24 mm across the full line.
Swipe sideways to see all columns
| Series / product | Frame depth | Frame sight line | Sash sight line | Glazing bead |
|---|---|---|---|---|
| 810FFixed | 81 mm (3.19") | 26 mm (1.02") | No sash | 24 mm (0.94") |
| 810CCasement | 81 mm (3.19") | 55 mm (2.17") | 76 mm (2.99") | 24 mm (0.94") |
| 810AAwning | 81 mm (3.19") | 31 mm (1.22") | 60 mm (2.36") | 24 mm (0.94") |
| 810TTTilt & turn | 81 mm (3.19") | 26 mm (1.02") | 42 mm (1.65") | 24 mm (0.94") |
| 810FSFixed | 85 mm (3.35") | 48 mm (1.89") | 24.7 mm (0.97") | 24 mm (0.94") |
| 810CSCasement | 85 mm (3.35") | 48 mm (1.89") | 24.7 mm (0.97") | 24 mm (0.94") |
| 810TTSTilt & turn | 85 mm (3.35") | 48 mm (1.89") | 24.7 mm (0.97") | 24 mm (0.94") |
| 830DHDouble hung | 83 mm (3.27") | 64.55 mm (2.54") | 47.62 mm (1.87") | 24 mm (0.94") |
| Axis™ 810Swing door | 81 mm (3.19") | 40 mm (1.57") | 86 mm (3.39") | 24 mm (0.94") |
| AeroFold™ 880Bi-folding door | 88 mm (3.46") | 75 mm (2.95") | 63 mm (2.48") | 24 mm (0.94") |
| AeroGlide™ 1500Sliding glass door | 150 mm (5.91") | Pending | Pending | 24 mm (0.94") |
Ranges across available glazing unless marked. Wind is design pressure; water is the no-leak pressure.
Swipe sideways to see all columns
| Series / product | U-factor | SHGC | VT | CI / CR | Air Infiltration | Wind | Water |
|---|---|---|---|---|---|---|---|
| 810FFixed | 0.14 – 0.28 | 0.16 – 0.45 | 0.36 – 0.62 | CI 58 – 82 | ≤0.30 cfm/ft² @ 1.57 psf | ±2880 Pa±60.1 psf | 720 Pa15.0 psf |
| 810CCasement | 0.22 – 0.31 | 0.12 – 0.31 | 0.24 – 0.42 | CI 56 – 78 | ≤0.30 cfm/ft² @ 1.57 psf | ±2880 Pa±60.1 psf | 720 Pa15.0 psf |
| 810AAwning | 0.21 – 0.31 | 0.12 – 0.31 | 0.24 – 0.42 | CI 56 – 78 | ≤0.30 cfm/ft² @ 1.57 psf | ±2400 Pa±50.1 psf | 580 Pa12.1 psf |
| 810TTTilt & turn | 0.17 – 0.30 | 0.14 – 0.41 | 0.29 – 0.55 | CI 55 – 77 | ≤0.30 cfm/ft² @ 1.57 psf | ±2880 Pa±60.1 psf | 720 Pa15.0 psf |
| 810FSFixed | 0.18 – 0.34 | 0.18 – 0.54 | 0.32 – 0.67 | CR 50 – 68 | ≤0.30 cfm/ft² @ 1.57 psf | ±2880 Pa±60.1 psf | 720 Pa15.0 psf |
| 810CSCasement | 0.21 – 0.34 | 0.17 – 0.49 | 0.28 – 0.61 | CR 58 – 64 | ≤0.30 cfm/ft² @ 1.57 psf | ±2400 Pa±50.1 psf | 580 Pa12.1 psf |
| 810TTSTilt & turn | 0.21 – 0.34 | 0.17 – 0.49 | 0.28 – 0.61 | CR 58 – 64 | ≤0.30 cfm/ft² @ 1.57 psf | ±2400 Pa±50.1 psf | 580 Pa12.1 psf |
| 830DH*Double hung | 0.35 | 0.27 – 0.43 | 0.45 – 0.59 | CR 32 – 33 | ≤0.30 cfm/ft² @ 1.57 psf | Not yet published | Not yet published |
| Axis™ 810†Swing door | 0.46 | 0.12 | 0.23 | CR 26 | ≤0.30 cfm/ft² @ 1.57 psf | ±1920 Pa±40.1 psf | 580 Pa12.1 psf |
| AeroFold™ 880Bi-folding door | 0.33 – 0.42 | 0.25 – 0.35 | 0.37 – 0.47 | CR 45 – 46 | ≤0.50 cfm/ft² @ 1.57 psf | ±1440 Pa±30.1 psf | 220 Pa4.6 psf |
| AeroGlide™ 1500*†Sliding glass door | 0.55 | 0.22 | 0.45 | CR 27 | Not yet published | Not yet published | Not yet published |
Common construction across the Axiom™, Axis™, AeroFold™ and AeroGlide™ ranges.
| Aluminum profile | 6063-T5 / 6060-T66 |
|---|---|
| Wall thickness | Window 1.8 mm (0.07") · Door 2.2 mm (0.09") · 810FS / 810TTS 2.0 mm (0.08") |
| Surface treatment | Powder coat · fluorocarbon · anodized |
| Thermal break | PA66-GF25 nylon, equilibrium-line design |
| Sealing gasket | High-quality EPDM, triple seal |
| Glazing | Double standard / triple optional, tempered |
| Spacer & fill | TPS / warm edge, argon filled, Low-E |
| Hardware | SIEGENIA · HOPPE · CMECH |
| Max fixed sash | 6000 × 3300 mm (236 × 130") |
| Max sash, awning | 2000 × 2000 mm (79 × 79") |
| Max sash, tilt-turn | 1200 × 2400 mm (47 × 94") · 810TTS 1200 × 1800 mm (47 × 71") |
| Max sash, door | 1200 × 2800 mm (47 × 110") |
| Sound reduction | STC 37 (ASTM E413-22); whole-window Rw minimum 35 dB |
| Drainage | Hidden drainage or weep holes |
Door configurations and maximum spans. Set per project from the signed drawings.
| Axis™ 810 | Single leaf, double leaf, or leaf with fixed sidelite. Sash to 1200 × 2800 mm (47 × 110"). |
|---|---|
| AeroFold™ 880 | 2+0, 3+0, 4+0, 2+1, 3+1, 2+2, 4+2 and 3+3 (see catalog p. 23). Panels virtually unlimited in line. |
| AeroGlide™ 1500 | Two-panel (XX) and multi-track configurations (see catalog p. 25). 218.2 mm (8.59") sill. |
Not shown in this catalog. Availability and specifications confirmed per project. Ask your dealer.
Performance standards and test methods referenced for the Mosaic 2027 line.
| Certified to | NAFS / CSA (AAMA/WDMA/CSA 101/I.S.2/A440-17) |
|---|---|
| Water penetration | No-leak pressure by product is listed in the performance table above. |
| Sound insulation | STC 37 · ≥ OITC 37 (ASTM E1332-22) |
| Thermal testing | NFRC 100 (ANSI/NFRC 100-2023) |
| Solar / optical | NFRC 200 (ANSI/NFRC 200-2023) |
| Condensation | NFRC 500 (ANSI/NFRC 500-2023) |
| Thermal barrier | PA66 GF25 nylon strip |
| Coatings | Architectural-grade polyester, AAMA 2604 / 2605 available |
